Best Rooms for Casement & Top-Hung Windows
- Bathrooms — top-hung stays open in light rain; compression seal keeps dust out. Most common use of this calculator.
- Kitchen service windows — vent above platform without a shutter swinging into the work area.
- Staircase & utility vents — high openings where directed airflow matters more than clear width.
- Bedroom side vents (small) — when a full 3-track slider is overkill; pair with sliding on the main balcony wall instead.
Not ideal for: wide balcony walls, floor-to-ceiling living glass — use system sliding series on those openings.
Casement & Openable Series Guide — 40mm to 72mm
Casement (openable) systems have fewer profile series than sliding — but each one is engineered for a specific job. The full range: 40, 45, 50, 52, 65 and 72mm. Top hung, side swing, uplift doors and style doors are all built from this same section family, and so are entrance doors and French doors.
| Series | Max Height | Max Width/Shutter | Glass | Best For | Honest Limitation |
|---|
| 40–45mm | 6–7 ft | 3 ft | DGU up to 22mm | Flats, apartments, builder projects | Lightweight, low depth — keep shutters small |
| 50–52mm | 10 ft | Standard door widths | DGU up to 38mm | Premium homes, entrance doors | Higher cost |
| 65–72mm | 12 ft | 3.5–4 ft | Single 5–12mm / laminated up to 13.52mm only — no DGU | Offices, safety doors, automatic access | DGU not possible |
Why choose casement over sliding at all?
- Maximum opening space — the full frame opens, not just half. Perfect where the window itself is small: bathrooms, kitchens, staircase windows.
- Better sealing — the shutter presses shut against EPDM gaskets, controlling dust and sound to the maximum level.
- Better security — multi-point safety locks are far stronger than sliding latches, which is why entrance and French doors are built from this family.
Honest disadvantages:
- The shutter needs clear swing space — inside or outside. In tight rooms or near furniture, a casement fights for space that sliding doesn't need.
- Shutter width is limited (3 ft in 40–45mm; 3.5–4 ft even in 65–72mm) — wide openings need multiple shutters or a sliding system instead.
- Hinges carry the full shutter weight every single open/close — quality hinges are non-negotiable, and heavy shutters on cheap hinges sag within a couple of years.
